40 Frame Commercial Electric Honey Extractor for Beekeeping

Honey Extractor

40 Frame Commercial Electric Honey Extractor for Beekeeping

Item Number : HE-40E

Price varies based on specs and customizations


Capacity
40 Standard Langstroth Frames (Shallow, Medium, or Deep)
Motor Power
550W
Material
Food-Grade Stainless Steel (Barrel, Reel), Powder-Coated Steel (Stand)
ISO & CE icon

Shipping:

Contact us to get shipping details Enjoy On-time Dispatch Guarantee.

Get Quote

Why Choose Us

Reliable Partner

Easy ordering process, quality products, and dedicated support for your business success.

Easy Process Quality Assured Dedicated Support

Elevate your honey harvesting capabilities with the HONESTBEE 40-Frame Commercial Electric Honey Extractor. This machine is a masterclass in efficiency, designed specifically for commercial apiaries and beekeeping operations that demand high throughput and unwavering reliability. Combining robust stainless steel construction with a powerful, programmable motor, this extractor is built to be a dependable workhorse in any professional honey house.

Electric Honey Extractor

Detailed Product Description

From its foundation to its control system, this electric honey extractor is engineered for performance, durability, and ease of use in a demanding commercial environment.

Electric Honey Extractor

Heavy-Duty Stainless Steel Construction

The extractor features a large-diameter drum and a precision-engineered inner basket, both crafted from high-quality, food-grade stainless steel. This ensures maximum hygiene, prevents corrosion, and simplifies the cleaning process. The unit is mounted on a sturdy, powder-coated steel stand with adjustable legs, providing a stable platform that can be leveled on any surface.

  • Barrel Diameter: 110 cm
  • Barrel Height: 73 cm

Electric Honey Extractor

40-Frame High-Capacity Radial Reel

The heart of this honey extractor is its 40-frame radial reel. The radial design allows frames to be loaded with the top bars facing outwards, enabling honey to be extracted from both sides of the comb simultaneously. This eliminates the time-consuming step of stopping the machine to flip frames, drastically increasing the speed of your entire extraction workflow.

  • Inner Basket Frame Size: 42 cm x 26 cm (Accommodates standard Langstroth frames)

Electric Honey Extractor

Powerful and Programmable Motor Drive

This unit is powered by a robust 550W electric motor coupled with a high-torque gearbox, mounted securely on top. The entire system is managed by a sophisticated Variable Frequency Drive (VFD) controller housed in a durable stainless steel enclosure.

Controller Features:

  • Variable Speed Control: The digital controller allows for precise adjustment of the rotational speed, enabling a gentle start to protect delicate combs and a powerful spin for complete extraction.
  • Safety Switch: A prominent, easy-access power switch with a protective cover ensures safe operation.
  • Voltage Options: The standard model operates on 220V, with customization for 110V available to meet international market requirements.

Electric Honey Extractor

Professional-Grade Features

  • Hinged Stainless Steel Lids: The two-piece hinged lid allows for easy loading and unloading of the reel while keeping the interior protected from dust and debris during operation.
  • Welded Honey Gate: A high-quality stainless steel honey gate is welded at the lowest point of the conical bottom, ensuring a leak-proof seal and allowing for fast, complete drainage of the extracted honey.

Key Advantages

  • High Throughput: The 40-frame capacity makes this an ideal honey extractor for significantly reducing processing time in medium to large-scale apiaries.
  • Automated Efficiency: The programmable electric motor and VFD controller reduce manual labor and ensure consistent, damage-free extraction.
  • Built to Last: With a full stainless steel drum and basket and a heavy-duty frame, this machine is a long-term investment built for years of reliable service.
  • Hygienic and Food-Safe: The use of food-grade stainless steel and an easy-to-clean design helps producers maintain the highest quality standards for their honey.

Applications and Value Proposition

For Beekeeping Supply Dealers:

The HONESTBEE 40-Frame Electric Honey Extractor is a cornerstone product for your commercial beekeeping clients. It fills a crucial market need for a high-capacity, reliable, and affordable electric extractor. Offering this model, along with voltage customization, demonstrates your commitment to serving the professional market and will attract serious beekeepers looking to upgrade their operations.

For Commercial Beekeepers:

This honey extractor is a productivity multiplier. Its large capacity and automated features will drastically cut down on your labor costs and the time spent in the honey house. It is the perfect investment for a growing apiary, enabling you to scale your business and increase profitability by streamlining your harvest.

Product Specifications Summary

Feature Specification & Benefit
Product Type 40-Frame Commercial Electric Radial Honey Extractor
Capacity 40 Standard Langstroth Frames (Shallow, Medium, or Deep)
Material Food-Grade Stainless Steel (Barrel, Reel), Powder-Coated Steel (Stand)
Motor Power 550W
Controller Variable Frequency Drive (VFD) with adjustable speed
Voltage 220V (Standard) / 110V (Customizable)
Barrel Diameter 110 cm
Barrel Height 73 cm
Basket Frame Size 42 cm x 26 cm

Upgrade Your Extraction Line with HONESTBEE

For suppliers and commercial beekeepers who require a powerful, durable, and high-capacity extraction solution, the HONESTBEE 40-Frame Electric Honey Extractor delivers unmatched value and performance. Contact our wholesale department today to request a quote, discuss customization options, and learn about our partnership programs. It's time to make your honey harvest faster and more profitable.
